- Features
- Specifications
Warranty Length
- 10-year limited warranty on aluminized gas heat exchanger
- 5-year limited warranty on compressor
- 3-year limited warranty on Eco-Last Coil System
- 1-year limited warranty on covered components
Features
- Compatible with 20+ years of existing units, eliminating the cost of an adaptor curb in many replacement jobs
- Eco-Last™ Coil System uses up to 52% less refrigerant, is up to 59% lighter, and has up to 20% fewer brazed joints than regular rooftop unit coils (standard on ZC and ZG models)
- Being 18% lighter than other like units, makes Z-Series units easier to lift and move*
- Exact charge is weighed in at the factory to ensure precise operation
- Scroll compressor on all units for reliable long-term operation
- Goes through a 200-point quality check and a rigorous run-testing regimen before leaving the factory
- High-pressure switch guards the compressor from extreme operating conditions
- Common utility connection points allow for faster and easier installations
Cooling Capacity:
3.0 Ton Cooling
Heating Capacity:
No Heating Capacity
Height:
38.875
Length:
85.25
Material:
GC875
Number of Phases:
1 Phase
Power Rating:
60 Hz
Voltage Rating:
208/230v 1ph 60 hz
Width:
47.0
Efficiency:
Not Rated
