Features
Product:
- R1 Scroll (Variable Speed) Compressor
- Auto operation
- Auto restart
- Self diagnosis
- Defrost / Deicing
- Low ambient cooling down to 14°F
- Soft start
- Restart delay (3 minutes)
- Factory installed Drain Pan Heater
Performance:
- Nominal Cooling Capacity : 48,000 (Btu/h)
- Nominal Heating Capacity : 52,000 (Btu/h)
Piping:
- Refrigerant Charge (lbs) : 11.46
- Liquid Line (OD) : 3/8" (1 Each)
- Vapor Line (OD): 3/4" (1 Each)
- Max Total Piping² : 475.7 ft
- Max ODU to IDU Piping: 229.6 ft
- Piping Length (no add'l refrigerant, ft): 180.4
- Max Elevation between ODU and IDU: 98.4 ft
- Max Elevation between IDU and IDU: 49.2 ft
Unit Data:
- Refrigerant Type R410A
- Refrigerant Control EEV
- Sound Pressure (Cool/Heat) +/-3 dB(A) 54/56
- Net Unit Weight (lbs) : 218
- Shipping Weight (lbs) : 243
- Heat Exchanger Coating GoldFin
- Min Number of Indoor Units: 2
- Max Number of Indoor Units: 8
Cooling Capacity:
48000 Btu/hr
Dimensions:
54-11/32 in H x 37-13/32 in W x 13 in D
EER Rating:
12.5
Flow Rate:
685 cfm
Fuse Size:
20 A
Heating Capacity:
52000 Btu/hr
HSPF Rating:
10
Maximum Piping Length:
246 ft
Mounting Type:
Wall
Power Source:
208/230 VAC, 1 ph, 60 Hz
Refrigerant Type:
R-410A
SEER Rating:
17.5
Sound Level:
56 dBA
Suction Line Size:
1/4 in
