Features
- Hot start
- Inverter (variable speed)
- Auto restart
- Control lock
- W2 terminal connection
- Group control
- Timer (on/off)
- Sleep mode
- Optional Wi-Fi Control
- Built in dry contact
- ODU Drain Pan Heater
- Night Quiet Function
- IDU compatible with Multi F (18k, 24k, 36k models)
Standard Approvals
- AHRI Certified
- CSA Certified
Cooling Capacity:
42000 Btu/hr
Dimensions:
54-11/32 in H x 37-13/32 in W x 13 in D
EER Rating:
12.5
Flow Rate:
4238 cfm
Fuse Size:
22 A
Heating Capacity:
48000 Btu/hr
HSPF Rating:
11
Maximum Piping Length:
246 ft
Mounting Type:
Wall
Power Source:
208/230 VAC, 1 ph, 60 Hz
Refrigerant Type:
R-410A
SEER Rating:
19.6
Sound Level:
56 dBA
Suction Line Size:
5/8 in
