Features
- 24-Hour on/off timer
- 4-Way auto swing
- Auto changeover
- Auto restart
- Jet cool/Jet heat
- Builtin low ambient standard, down to 14°F (cooling mode)
- Chaos wind
- Condensate sensor connection
- Defrost control
- Dehumidifying mode
- Hot start
- Self Diagnosis
- Washable Filter
- Soft dry operation
- Self cleaning indoor coil
- Builtin base pan heater
- Builtin WiFi via Smart ThinQ app
- Cooling only/heating only function
Standard Approvals
- AHRI Certified
- CSA Certified
Compressor Type:
Twin Rotary
Cooling Capacity:
15000 Btu/hr
Dimensions:
32-3/4 in H x 37-13/32 in W x 13 in D
EER Rating:
15
Flow Rate:
389/495/813 cfm
Fuse Size:
19 A
Heating Capacity:
18000 Btu/hr
HSPF Rating:
13.5
Maximum Piping Length:
164 ft
Mounting Type:
Wall
Power Source:
208/230 VAC, 1 ph, 60 Hz
Refrigerant Type:
R-410A
SEER Rating:
25
Sound Level:
56 dBA
Suction Line Size:
3/8 in
