Warranty Length
- Limited Lifetime
Features
- Kinesis™ technology with concealed sensor allows for a clean aesthetic and provides extraordinarily accurate and reliable actuation in varying installation environments
- Design-forward aesthetic for commercial bathroom spaces
- Vandal-resistant aerator
- Recommended products/accessories - K-13480 AC single supply or K-13480-A AC single supply or K-13481 multi-outlet power supply or K-13481-A multi-outlet power supply
- Below-counter valving reduces the faucet footprint and provides easier service
- Operates via battery, plug-in AC power, or Hybrid Energy System (each sold separately)
- On-demand usage with 30-second maximum continual run cycle to prevent vandalism and save water
- 18 in (457 mm) stainless steel braided flexible supply hose for easy installation
- Concealed mechanical mixer sold separately
Standard Approvals
- ADA Compliant
- ASME A112.18.1/CSA B125.1/B651
- DOE - Energy Policy Act 1992
- CEC Certified
- ICC/ANSI A117.1
- NSF/ANSI 61/372
- OBC Code
Collection:
Composed®
Commercial/Residential:
Commercial
Connection Size:
3/8 in
Connection Type:
Compression
Drain Type:
Grid
Finish:
Polished Chrome
Flow Rate:
0.5 gpm
Function:
Touchless
Hose Size:
18 in L
Installation Type:
Single-hole
Material:
Brass
Maximum Deck Thickness:
1-1/8 in
Mounting Type:
Deck
Number of Faucet Holes:
1
Overall Height:
5-1/2"
Overall Length:
5-13/16"
Overall Width:
2"
Series:
103C36-SANA
Spout Height:
4-7/8 in
Spout Reach:
5-13/16 in
Spout Type:
Fixed
Type:
Lavatory Faucets
Valve/Cartridge Type:
Cast Brass
Style:
Contemporary
