Features
- Hot Start
- Inverter (variable speed)
- Auto restart
- Control lock
- Group control
- Timer (on/off)
- Sleep Mode
- Optional Wi-Fi Control
- Built in dry contact
- ESP (External Static Pressure) Control
Standard Approvals
- AHRI Certified
- CSA Certified
Compressor Type:
Twin Rotary
Cooling Capacity:
30 EER
Dimensions:
32-27/32 in H x 37-13/32 in W x 13 in D
EER Rating:
13.30
Flow Rate:
640 cfm
Fuse Size:
1.1 A
Heating Capacity:
20000 Btu/hr
HSPF Rating:
10.4
Maximum Piping Length:
164 ft
Mounting Type:
Floor
Number of Phases:
1
Power Source:
208/230 VAC, 1 ph, 60 Hz
Refrigerant Type:
R-410A
SEER Rating:
19.2
Size:
18 X 21.25
Sound Level:
52 dBA
Suction Line Size:
5/8 in
Voltage Rating:
208-230V
Commercial/Residential:
Residential/Light Commercial
