Features
- Thermal actuation technology for precise temperature control
- Locking mechanism secures temperature setting
- Adjustment cap with locking feature
- Integral filter washers and check valves
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- Viega ProPress connections are factory-installed fitting on each end of the approved/certified assembly
Standard Approvals
- ASSE 1017
- ASSE 1069
- ASSE 1070
- IAPMO Listed and cUPC listed
- PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
Body Material:
Copper Silicon Alloy
Domestic/Import:
Domestic
End Style:
Threaded Union
Flow Capacity:
20 gpm
Inlet to Outlet Length:
5-5/16 in
Nominal Size:
1 in
Pressure Rating:
150 psi
Softgoods Material:
Buna-N®/EPDM O-Ring
Temperature Rating:
200 deg F
Trim Material:
Stainless Steel
