Warranty Length
- 1 Year Limited
Features
- No special tools required for servicing
- Compact space saving design
- Acetyl bonnet acts as freeze plug to prevent body damage
- Female NPT inlet and outlet with quarter turn shut-offs
- Easy maintenance of internal parts
- Replaceable plastic seat
- O-ring bonnet seal for less possibility of fouling
- The wetted surface of this product contacted by consumable water contains less than 0.25% of lead by weight
- Test cocks positioned for easy testing and winterization
- Silicone seat disc for durability
Standard Approvals
- ANSI/ASSE 1020
- Approved by the foundation for Cross-Connection Control and Hydraulic Research at the University of Southern California
- cCSAus Certified
- USC Manual Section 10
- UPC Listed
- PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
Backflow Type:
Vacuum Breaker
Ball Valve/Gate Valve Type:
Quarter-Turn Ball Valve
Body Material:
Cast Copper Silicon Alloy
Domestic/Import:
Domestic
End Style:
Female Threaded NPT
Flow Rate:
7.5 fps
Media:
Water
Nominal Size:
1/2 in
Port Type:
Drain/Blow Down
Pressure Rating:
150 psi
Temperature Rating:
33 to 140 deg F
