Warranty Length
- 1 Year Limited
Features
- Bronze body for durability
- Ease of maintenance only one cover
- Replaceable seats and seat discs
- Cast bronze construction
- Top mounted resilient seated test cocks
- Modular compact design
- Low pressure drop
- Top entry
Standard Approvals
- Approved By The Foundation For Cross-Connection Control And Hydraulic Research At The University Of Southern California
- ASSE 1015
- AWWA C510
- CSA B64.5
- IAPMO PS31
- UPC Listed
- PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm.
Backflow Type:
Double Check Valve
Ball Valve/Gate Valve Type:
Quarter-Turn Ball Valve
Body Material:
Bronze
Domestic/Import:
Domestic
End Style:
Female Threaded NPT
Flow Rate:
7.5 fps
Media:
Water
Nominal Size:
2 in
Pressure Rating:
175 psi
Temperature Rating:
33 to 180 deg F
Type:
Inline
