Mueller Steam Specialty™ 11M 3/4 Wye Strainer, 3/4 in Nominal, 3-3/4 in OAL, FNPT Connection, Graphite Softgoods
| Brand | Mueller Steam Specialty™ |
| MFR Part No | M6700188 |
| TSCO Part Number | 416004 |
- Features
- Specifications
- Documents
Warranty Length
- 1 year
Features
- Machined seats in both body and cap align and lock the screen in place to stop sediment bypass
- Screwed cap
- Gasketed cap is used for easy disassembly and assembly, many others use Loctite, rendering disassembly virtually impossible
- Self-cleaning is accomplished by opening the plug or valve connected to the blow-off outlet
- Outlets are NPT tapped
- Generously proportioned bodies
- Open area ratio much greater than pipe size, ensures low pressure drop
- Metal filled graphite gasket
Standard Approvals
- ASTM A-126 Grade B Body
- BAA Compliant
- US Green Building Council Member
Blow-Off Size:
3/8 in NPT
Body Material:
Cast Iron
Connection Type:
FNPT
Domestic/Import:
Domestic
Grade:
B
Nominal Size:
3/4 in
Overall Length:
3-3/4 in
Softgoods Material:
Graphite
