Warranty Length
- 5 Years
Features
- Pulsation resistant liquid filled stainless steel case
- Brass or lead free brass and stainless steel internals
- Restricted orifice standard on dual scale
- Crimp-on bezel and ring
- White aluminum with black and red markings dial
- OT 59 brass or stainless steel movement
- Aluminum, anodized black pointer
- Welding - brass, silver alloy, 316 stainless steel - TIG
- Over-pressure limit - 25% for pressures up to 1450 psi (9998 kPa), 15% for pressures over 1450 psi (9998 kPa)
- Socket gasket Buna-N for two-piece internal socket seal
- Buna-N fill plug
- Lens ring gasket - silicone rubber
- Maximum 75% of full-scale value working pressure
- IP65 enclosure rating
- Polycarbonate lens
Standard Approvals
- ASME B40.100
- CRN Registered
- RoHS Compliant
Accuracy:
+/- 1.5 %
Connection Size:
1/4 in NPT
Dial Diameter:
2-1/2 in
Liquid Filled:
Glycerin
Material:
304 Stainless Steel Case
Pressure Range:
30 in Hg/0 to 30 psi
Temperature Rating:
-40 to 200 deg F
Type:
Dual Scale
