WINTERS PFQ800 Dual Scale Pressure Gauge, 0 to 15 psi/kPa, 1/4 in NPT Connection, 2-1/2 in Dial, +/- 1.5 %, Glycerin Liquid Filled
WINTERS

WINTERS PFQ800 Dual Scale Pressure Gauge, 0 to 15 psi/kPa, 1/4 in NPT Connection, 2-1/2 in Dial, +/- 1.5 %, Glycerin Liquid Filled

BrandWINTERS
MFR Part NoPFQ800
TSCO Part Number412102

Warranty Length

  • 5 Years

Features

  • Pulsation resistant liquid filled stainless steel case
  • Brass or lead free brass and stainless steel internals
  • Restricted orifice standard on dual scale
  • Crimp-on bezel and ring
  • White aluminum with black and red markings dial
  • OT 59 brass or stainless steel movement
  • Aluminum, anodized black pointer
  • Welding - brass, silver alloy, 316 stainless steel - TIG
  • Over-pressure limit - 25% for pressures up to 1450 psi (9998 kPa), 15% for pressures over 1450 psi (9998 kPa)
  • Socket gasket Buna-N for two-piece internal socket seal
  • Buna-N fill plug
  • Lens ring gasket - silicone rubber
  • Maximum 75% of full-scale value working pressure
  • IP65 enclosure rating
  • Polycarbonate lens

Standard Approvals

  • ASME B40.100
  • CRN Registered
  • RoHS Compliant
