WINTERS PLP301 Low Pressure Gauge, 0 to 32 in H2O, 1/4 in NPT Connection, 2-1/2 in Dial, +/- 3-2-3 %
WINTERS

WINTERS PLP301 Low Pressure Gauge, 0 to 32 in H2O, 1/4 in NPT Connection, 2-1/2 in Dial, +/- 3-2-3 %

BrandWINTERS
MFR Part NoPLP301
TSCO Part Number410865

Warranty Length

  • 5 Years

Features

  • Highly accurate reading of low pressures
  • Brass or stainless steel wetted parts
  • Ranges from 15 in H2O/oz to 10 psi
  • Over-pressure protection on some models (OP)
  • Suitable for measuring gaseous media both corrosive and non-corrosive
  • Used to measure natural gas pressure as well as air flow indication and leak detection
  • Brass socket
  • Aluminum ring
  • Brass movement
  • Aluminum, anodized black pointer
  • Solder/brazed welding
  • IP52 enclosure rating
  • Polycarbonate lens

Standard Approvals

  • ASME B40.100
  • ANSI/ASME Grade B
  • CRN Registered
