Little Giant® NXTGen™ 554530 VCMX-20 Automatic Condensate Removal Pump, 84 gph Flow Rate, 1-1/8 in Inlet x 3/8 in OD Barbed Outlet, 21 ft Shutoff Head, 93 W Power Rating
Part #:
338414
MFG #
554530
Brand:
Little Giant®
- Description
- Specifications
- Features
- Documents
Little Giant® NXTGen™ Condensate Removal Pump, Automatic, Series: VCMX-20, 84 gph, 1-1/8 in Inlet, 3/8 in OD Barbed Outlet, 21 ft Shutoff Head, 93 W, 1.5 A 115 VAC 60 Hz 1/30 hp, 9.1 psi Maximum, Wall Mount, 140 deg F, ABS, 10.2 in L x 4.8 in W x 6.5 in H
Flow Rate:
84 gph
Inlet Size:
1-1/8 in
Material:
ABS
Mounting Type:
Wall
Outlet Size:
3/8 in OD Barbed
Power Rating:
93 W
Temperature Rating:
140 deg F
Application Type:
For removal of condensate from air conditioners, high efficiency gas furnace condensation and condensing boilers
Electrical Ratings:
1.5 A 115 VAC 60 Hz 1/30 hp
Features
External test/run lever|Slim footprint|Vertical centrifugal pump design|For models with safety overflow switch - dual function NO and NC operation (set to NO from factory for equipment shut down connection)|Models equipped with safety overflow switch include two 5 in switch lead wires|3/8 in OD barbed 1/4-turn quick release, locking discharge adapter with built-in check valve|Rubber feet for vibration/noise dampening|Anti-sweat tank sleeve included on select models and available separately for all others|(3) 1-1/8 in Dia inlet openings, two fitted with removable cap plug (3 + 1 inlet openings for models without safety overflow switch)|Recessed tank sump|Oil resistant tank and check valve|Thermally protected, fan cooled motor|6 ft, 3-conductor cable with grounded 3-prong plug|ABS volute, polypropylene tank, impeller, ABS switch float, motor cover, acetal check valve
Standard Approvals
cCSAus Certified
