Warranty Length
- 25 Years
Features
- Fastest way to connect PEX, copper, CPVC, PE-RT or HDPE SDR-9 pipe
- Half the insertion force compared to SharkBite 1st Generation fittings
- Can be installed on wet lines and pressure tested immediately
- Stainless steel retainer adds strength and durability
- No special tools, crimping, soldering or glue required
- Can be rotated after installation
- No tube liner required for PEX
Standard Approvals
- ASSE 1061
- CSA B125.3
- NSF/ANSI 14
- NSF/ANSI/CAN 372
- ASTM E84
- CAN/ULC S102.2
- UL 263
- ASTM E119
- CAN/ULC S102
Dimensions:
1.2 in Dia x 2.4 in L
End Style:
Push-to-Connect
Fitting/Connector Type:
Reducing Coupling
Material:
Lead-Free DZR Brass
Nominal Size:
3/4 x 1/2 in
Pressure Rating:
250 psi
Temperature Rating:
200 deg F
