Features
- Test cocks are screwdriver slotted
- Internal relief valve for reduced installation clearances
- Lead free bronze body construction for durability
- NPT inlet and outlet connections
- Replaceable seats for an economical repair
- Single access cover and modular check construction for the ease of maintenance
- Features flood sensor with SentryPlus Alert technology to detect excessive water discharges from the relief valve
- Quarter turn full port resilient seated ball valve shutoffs
Standard Approvals
- 1-UL Listed
- PROP65: This product can expose you to chemicals including lead which is known to the State of California to cause cancer and birth defects or other reproductive harm
Videos
Backflow Type:
Reduced Pressure Zone
Ball Valve/Gate Valve Type:
Quarter-Turn Ball Valve
Body Material:
Copper Silicon Alloy
Dimensions:
21-3/8 in L x 8-3/4 in H
End Style:
FNPT
Finish:
Cast Copper Silicon Alloy
Media:
Water
Nominal Size:
2 in
Pressure Rating:
175 psi
Series:
LF009-FS
Temperature Rating:
33 to 180 deg F
