Allied Commercial™ 22K27A ML14XC1-048-463 14 SEER Air Conditioner, 4 Ton, 460V, 3 Phase, 60 Hz
| Brand | Allied Commercial™ |
| MFR Part No | 22K27A |
| TSCO Part Number | 1212851 |
- Features
- Specifications
- Documents
Features
- Outdoor Coil Fan
- Omniguard™
- Expansion Valve
- Defrost Control
- Scroll Compressor
- High Capacity Liquid Line Drier
- Four Way Reversing Valve
Standard Approvals
- AHRI Certified
- ETL certified (U.S. and Canada)
- ISO 9001 Registered
Cooling Capacity:
48000 Btu/hr
Dimensions:
37.25 in H x 28.25 in W x 28.25 in D
Heating Capacity:
No Heating Capacity
Motor HP:
1/6 hp
Motor RPM:
825 rpm
Mounting Type:
Resilient
Nominal Capacity:
4 ton
Number of Phases:
3
Power Source:
460 VAC, 3 ph, 60 Hz
Refrigerant Type:
R-410A
SEER Rating:
16
Series:
ML14XC1
Suction Line Size:
7/8 in
Voltage Rating:
460v 3ph 60 hz
Efficiency:
14.0 SEER
Height:
37.25
Length:
28.25
Width:
28.25
