- Features
- Specifications
- Documents
Warranty Length
- Limited Lifetime
Features
- 1 or 3-hole 8 in installation
- Pull-out spout swivels 120 deg for added convenience
- 59 in L hose provides outstanding reach
- Single handle kitchen faucets for exposed mounting on single and three hole sinks
- Spout is connected to valve body with a 53 in (1346 mm) long hose that extends to 34 in (864 mm) usable length
- Pull-out spout operates in an aerated or spray mode via an easy side-to-side push lever
- Lever or loop handle shall return to neutral position when faucet is turned off
- Red blue graphics on handle button to indicate hot cold temperature
- 3/8 in OD straight, staggered PEX supply tubes - 35 in (889 mm) and 36 in (914 mm) long
- Integral double check valves in spout
- 1.8 gpm at 60 psi
- Soft, rubber Touch-Clean spray holes allow you to easily wipe away calcium and lime build-up with the touch of a finger
- DIAMOND Seal Technology is less hassle to install and helps your faucet perform like new for life, reducing leak points and lasting twice as long as the industry standard
Standard Approvals
- ADA Compliant
- ASME A112.18.1
- ASME A112.18.6
- CSA B125.1
- ICC/ANSI A117.1
- No-Lead Compliant
- Water-Efficient
Center Distance:
8 in
Collection:
Signature™
Commercial/Residential:
Commercial
Connection Size:
3/8 in
Connection Type:
Compression
Domestic/Import:
Domestic
Finish:
Matte Black
Flow Rate:
1.8 gpm
Handle Type:
Lever
Hose Size:
59 in
Material:
Zinc
Maximum Deck Thickness:
2-1/2 in
Mounting Type:
Deck
Number of Faucet Holes:
1/3
Number of Handles:
1
Number of Spray Functions:
2
Side Spray(Y/N):
No
Spout Height:
10 in
Spout Reach:
9 in
Spout Type:
120 deg Swivel
Spray Pattern:
Aerated Stream/Full Body
Type:
Kitchen
Valve/Cartridge Type:
Euro-Motion DIAMOND™ Seal Valve
