Marathon™ by Mars® Replacement Oil Burner Motor, Split Phase, Oil Burner Motors Application, Capacitor Start Motors Special Features, 1/8 hp, 115 VAC, 2.8 A Full Load, 1 ph, 1725 rpm Speed, 1 Speed, Totally Enclosed Not Ventilated Enclosure, 48N Frame, 1 Service Factor, Ball Bearing, Flanged Mounting, 7.7 in Dimensions
Amperage Rating:
2.8 A Full Load
Mounting Type:
Flanged
Voltage Rating:
115 VAC
Application Type:
Oil Burner Motors
Bearing Type:
Ball
Horsepower:
1/8 hp
Phase:
1 ph
Enclosure Type:
Totally Enclosed Not Ventilated
Frame:
48N
Number of Speeds:
1
Service Factor:
1
Speed:
1725 rpm
Special Features:
Capacitor Start Motors
Features
Semi or totally enclosed steel frame 20 in long leads from a 1/2 in NPT opening Two-bolt, NEMA N/M flange direct mounting Manual overload protection
