Features
- ASTM F877 specification for crosslinked polyethylene (PEX) plastic hot and cold-water distribution systems
- ASTM F1960 specification for cold expansion fittings with PEX reinforcing rings for use with cross-linked polyethylene (PEX) tubing
- ASTM E84 test method for surface burning characteristics of building materials
- ASTM E814 test method for fire tests of penetration firestop systems
- ASTM E119 test methods for fire tests of building construction and materials
Standard Approvals
- ASTM E84/E119/E814/F877/F1960
- CAN/CSA B137.5
- cNSFus-pw/rfh
- cQAIus P32
- HUD MR 1269
- IBC Code
- ICC-ES-PMG-1006/1012
- IMC Code
- IPC Code
- IRC Code
- NPC of Canada
- NSF 14/61
- NSPC
- ULC/ORD-C199P
- UL 1821
- UPC Listed
- UP Code
Domestic/Import:
Domestic
End Style:
ProPEX®
Fitting/Connector Type:
Tee
Length:
5-1/2 in
Material:
Modified Polyphenylsulfone
Nominal Size:
1-1/2 x 1-1/4 x 1-1/4 in
Pressure Rating:
150 psi
Temperature Rating:
210 deg F
