Features
- Comes standard with the Zoeller LED Plug that allows you to check for power at a quick glance
- Oil-filled motor and cast iron motor housing for optimal heat dissipation which prevents the pump from overheating
- Automatic high flow sump pump with a time-tested, preset, built-in snap action switch that makes for easy installation
- Corrosion resistant engineered plastic vortex impeller to allow free passage of solids which prevents clogging and lessens downtime
- Stainless steel float guard that prevents material or debris from collecting on the float ensuring proper operation every time
- Solid, buoyant, polypropylene float to eliminate the possibility of water infiltration allowing the float to remain buoyant and functional at all times
- Powder-coated epoxy finish provides corrosion-resistance and extends the life of the pump in harsh environments
- Stainless steel screws, switch arm, handle and hardware to prevent rust and corrosion over the life of the pump
- 100 Percent Factory Tested - every pump is submerged in water and tested at the factory to ensure that it performs as expected when you receive it
Standard Approvals
- CSA/US Certified
- SSPMA Certified
- UL Listed
Amperage Rating:
9.4 A
Bearing Type:
Oil Fed
Flow Rate:
73 gpm
Frequency Rating:
60 Hz
Horsepower:
1/2 hp
Impeller Type:
Non-Clogging Vortex
Material:
Cast Iron
Maximum Head:
23 ft
Motor Speed:
1725 rpm
Outlet Size:
1-1/2 in
Phase:
1
Temperature Rating:
130 deg F
Voltage Rating:
115/230 VAC
