Warranty Length
- Limited Lifetime
Features
- DockNetik® magnetic docking system securely locks the spray head into place when not in use
- ProMotion® technology's light, quiet braided hose and swiveling ball joint make the pull down spray head easier and more comfortable to use
- Single-handle is simple to use and makes adjusting water temperature easy
- Temperature memory allows faucet to be turned on and off at the temperature set during prior usage
- Three-function pull-down sprayhead with touch-control allows you to switch between stream, Sweep spray and Boost technology
- Boost technology increases the flow rate by 30 Percent with the press of a button
- MasterClean sprayface features an easy-to-clean surface that withstands mineral buildup and maximizes spray performance
- High-arch gooseneck spout and 360 deg spout rotation offer superior clearance for filling pots and cleaning
- Sweep spray features specially angled nozzles that form a wide, powerful blade of water to sweep your dishes and sink clean
Standard Approvals
- ADA Compliant
- All Applicable US Federal and State Material Regulations
- ASME A112.18.1/CSA B125.1
- CEC Certified
- CSA B651
- DOE Energy Policy Act 1992
- ICC/ANSI A117.1
- NSF/ANSI 61/372
Videos
Commercial/Residential:
Residential
Connection Size:
3/8 in
Connection Type:
Compression
Faucet Hole Size:
1-5/16 in Dia
Flow Rate:
1.5 gpm
Handle Type:
Lever
Installation Type:
Deck-mount
Material:
Brass
Maximum Deck Thickness:
2-1/2 in
Mounting Type:
Deck
Number of Faucet Holes:
1
Number of Handles:
1
Number of Spray Functions:
3
Overall Height:
15-3/8 in
Overall Length:
8 in
Overall Width:
8 in
Side Spray(Y/N):
No
Spout Height:
8-5/8 in
Spout Reach:
8 in
Spout Type:
360 deg High-Arc Gooseneck
Spray Pattern:
Boost/Stream/Sweep®
Valve/Cartridge Type:
Ceramic Disc Valve
Style:
Contemporary
