Features
- The only way to place a ball valve between two closely spaced tees
- Precision crafting achieves hydraulic separation
- Saves 36 minutes
- Replaces 5 components
- This valve is actuated by a blowout-proof stem
- Ball valve with integral spring check saves labor, space, and leak paths
Standard Approvals
- PROP65: This product can expose you to chemicals including Lead, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Actuator Type:
Reversible Handle
Body Material:
Brass
Domestic/Import:
Import
End Style:
Press
Nominal Size:
1-1/4 in
Port Type:
Full
Pressure Rating:
250 psi
Series:
8864
Temperature Rating:
250 deg F
